LMT4 Electric Vehicle Ceramic Automotive Fuse 150VDC 32A 40A 50A 60A 80A 100A

Name: LMT4 Electric Vehicle Ceramic Automotive Fuse 150VDC 32A 40A 50A 60A 80A 100A
Brand: AMPFORT
Price: 1 USD

Wholesale LMT4 Electric Vehicle Ceramic Automotive Fuse 150VDC 32A 40A 50A 60A 80A 100A from china suppliers

Brand Name : AMPFORT

Model Number : LMT4

Certification : CE/UL/VDE/KC/ROHS

Place of Origin : Dongguan,China

MOQ : 100pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 100000Piece/Weekly

Delivery Time : 10-15 WORKDAYS

Packaging Details : Standard carton

Name : Electric Vehicle Fuse

Breaking Capacity : 10KA

Rated current : 20~600A

Rated voltage : 150VDC

Type : Single or Twins

Stud-mount : M6/M8

Body Material : Ceramic

Halogen Free : Yes

Lead Free : Yes

Mounting Type : Surface Mount

Operating Temperature : -55°C to 125°C

Product Name : Surface Mount Fuses

Terminal Type : Radial

Time-Delay : Yes

Contact Now

LMT4 Electric Vehicle Ceramic Automotive Fuse 150VDC 32A 40A 50A 60A 80A 100A 125A 150A 160A 180A 200A 250A 300A 400A 500A 600A

An EV (Electric Vehicle) is comprised of a number of expensive components, notably the electric motor and the battery pack. ASTM provides the more high standard and reliable EV fuses for the various EV Applications.

General purpose fuse for EV/HEV Stud-mount, optional for other installtion 150Vdc ideal for EV or HEV application Execllent DC performance Special designed fuse base for vehicle situation

HEV

Electrical Characteristics for Series

Electrical Characteristics
% of Ampere Rating (A)	Operating
% of Ampere Rating (A)	Min	Max
200%	1	300
300%	0.2	30
500%	0.1	10

Ordering info

Type	Ordering P/N	Rated Current (A)	Rated Voltage (DCV)	Breaking Capacity (A)	1.0In Typical Voltage drop (mv)	1.0In Typical Power loss


Single	LMT4-20-XX	20	150	10000	145	2.9
	LMT4-25-XX	25			140	3.5
	LMT4-32-XX	32			135	4.3
	LMT4-40-XX	40			125	5
	LMT4-50-XX	50			120	6
	LMT4-60-XX	60			117	7.5
	LMT4-80-XX	80			113	9
	LMT4-100-XX	100			110	11
	LMT4-125-XX	125			105	13
	LMT4-150-XX	150			112	17.8
	LMT4-160-XX	160			110	19
	LMT4-180-XX	180			105	19.5
	LMT4-200-XX	200			100	20
	LMT4-250-XX	250			83	20.7
	LMT4-300-XX	300			77	23.1
Twins	LMT4-400-YY	400			100	40
	LMT4-500-YY	500			90.5	45.2
	LMT4-600-YY	600			82	48.7

*Temperature Rise: <=45K with 60% of rated current

LMT4 Electric Vehicle Ceramic Automotive Fuse 150VDC 32A 40A 50A 60A 80A 100A

Cross Reference

SMD Fuse

ASTM P/N	Electrical Char.		Competitor
ASTM P/N	Voltage	Current	Bussmann	Littelfuse	SIBA	Schurter
12 100	24-72Vdc	0.25-30A	3216FF	437	154000	USF 1206
12 110	24-72Vdc	0.75-20A	CC12H	469/440	–	UST 1206
12 113	125Vac/dc	0.25-5A	3216LV	466	–	–
06 100	32Vdc	0.25-8A	0603FA	438	152000	USF 0603
06 110	32Vdc	1-8A	CC06H	441	–	–
06 122	63Vdc	0.25-1.5A	–	438	–	–
PB05	125Vac/dc	0.5-15A	6125FF	451	157000	–
PB02	125Vac/dc	0.25-7A	6125TD	452	158000	–
A121001	125Vdc	50A-125A	–	881	–	–
PB06	125Vac/72Vdc	20-50A	1025HC	456/881	–	–
PB07	72Vdc	40A ~ 60A	–	456SD	–	–
1040 100	350Vac/250Vdc	0.5-6.3A	1040FA	464	161000	UMK 250
1040 110	250Vac	1~5A	1040TD	462	160000	UMZ 250
A114508	500Vdc/350Vac	1~5A	–	885	–	–

PV Fuse

ASTM P/N	Electrical Char.		Competitor
ASTM P/N	Voltage	Current	Bussmann	Littelfuse	SIBA	Schurter
HV110.PV	1000Vdc	1-30A	PVxxA10F	SPF	50 215 28	ASO
A10gPV	1000Vdc	10~20A	–	SPF		–
AC10LgPV	1500Vdc	2.5/3.5/4A	PV-xxA14LF10F	SPXI	–	–
AC10XLgPV	1500Vdc	2-15A	PV-xxA14LF10F	SPXI	–	–

Cartridge Fuse

ASTM P/N	Electrical Char.		Competitor
ASTM P/N	Voltage	Current	Bussmann	Littelfuse	SIBA	Schurter
HV520	500Vac/400Vdc	0.5~20A	S505H	477	–	–
62 720	75Vdc	5-63A	TCP70	688	–	TGU
MV630	250Vac/150Vdc	20-50A	–	314	–	SUT-H
HV660	500Vac/dc	10-30A	FWH-xxA6F	505	70 125 40	A12FA 500V
HV681	500Vac/dc	10-30A	GBH-xxA6F	231	189020	SHF
HV610	600Vac/dc	0.2~12A	–	–	7009463	A12FA 660V
HV620	1000Vac/dc	0.2~3.15A	–	508	7017240	–
HV110	1000Vac/dc	0.44~15A	DMM-B	FLU	50 199 06	–

EV/HEV Fuse

ASTM P/N	Electrical Char.		Competitor
ASTM P/N	Voltage	Current	Bussmann	Littelfuse	Mersen	PEC
HV150/EV105C	500Vdc	5A-50A	EV10	0HEV	–	EVFG
EV145 A2205 A372103 A372805	500Vdc	50A-500A	EV20 EV30 EV40 EV50	20EV	MEV50A	EVFC EVFP
EV108 EV148 A2201 A372101	800Vdc	5A-400A	–	–	MEV70 (700Vdc)	–
EV1010 EV1410 A2210 A4305	1000Vdc	10A-500A	–	–	MEV100	–
